200 Series Inverted Bucket Steam Trap

SRV2S Stainless Steel Direct-Acting Pressure Reducing Valve

The SRV2S stainless steel direct-acting pressure reducing valve is compact and suitable for steam or gas systems such as compressed air. All parts in contact with the medium are made of stainless steel.

401-SH 501-SH Series Inverted Bucket Superheated Steam Traps

Vertical installation (bottom inlet, top outlet) Maximum pressure difference 105 bar, maximum displacement up to 430 kg/h



Features

401-SH/501-SH series inverted bucket superheated steam traps are specially designed to overcome various unfavorable factors such as overheating, high pressure and low load.

In order to make the steam trap work properly under extremely harsh working conditions, the valve adopts a unique inverted bucket type steam trap with a water collection chamber. The water collection chamber collects enough condensate to ensure that the water seal can be maintained during the entire discharge cycle. The small cup in the water collection chamber can float up and down at the side steam pipe mouth. When the condensate rises, it seals the steam inlet pipe. The condensate flows into the valve. Since the water collection chamber collects the condensate and allows steam to flow in from the bottom of the inverted bucket, the discharge valve is tightly closed during the water collection period, and there is no dripping phenomenon.

BPM Series Pressure Balanced Steam Traps

Any installation, maximum pressure difference 21bar, maximum displacement: (cold water 800Kg/h), (hot water 550Kg/h)



Materials

Valve body, valve cover: A105

Valve seat: stainless steel

Valve disc: stainless steel

Liquid capsule: 5°C, 15°C optional

Other internal parts: stainless steel

VTSZ Series Integrated Condensate Recovery Station

Features

VTSZ condensate recovery station is a compact standardized condensate recovery station that installs all components such as integrated tube bundle, steam trap, cut-off valve, etc. on the base bracket, and reasonably distributes the branch pipes on both sides.

Applicable to: centralized collection and transportation of condensate from industrial steam heating systems in petroleum, chemical industry, metallurgy, textile, papermaking, printing and dyeing, pharmaceuticals, power stations, etc.

Save assembly time on the construction site.

Save engineering costs and reduce procurement and design time.

The design and installation are flexible and convenient.

Long service life.

If the customer has special requirements for piping layout, the pipe bundle structure layout can be redesigned according to on-site requirements.

SFT44 SFT46 Series Float Steam Trap

Maximum pressure difference 32bar, maximum displacement up to 31000Kg/h



Features

The parallel upper and lower double valve discs are subjected to the same surface pressure inside the valve body, requiring only a small force to open. Even if the volume of the float is reduced, the large displacement function can still be ensured.

An anti-erosion baffle is installed in the valve body to prevent steam flow from hitting the float.

Built-in automatic air exhaust device, quick start, no air blockage, good performance in exhausting non-condensable gases.
